1998 Mooney M20M Tls Bravo
Single Engine Piston
Equipment & Features
- Seats
- 4
Aircraft Details
Seller reportedAvionics & Equipment
BTHand two electric attitude indicators. There is no vacuum system. Garmin GFC 500 Autopilot with flight director
altitude/VS/IAS pre-select glideslope coupling GPSS roll steering return to level (LVL)and Electronic Stability Protection (ESP). All autopilot servos were replaced with updated "mod 1" units in 2025. WAAS-capable Garmin 430W navigator
which can fly LPV approaches Garmin GTX 345 transponderADS-B in and out with Bluetooth KX 165 secondary NAV/COMM radio KMA 24 audio panel Dual main batteries
dual alternators external GPU plug Monroy long-range tanks118 gallons usable All fuel tanks stripped and re-sealed with the Weep-No-More process in 2012 TKS system certified for flight into known icing conditions (FIKI)
with dual pumps 115 cu ft integrated four-place oxygen systemwith a two-place O2D2 pulse-demand unit included Redline SideWinder battery-operated tow bar. One person can move the plane easily
even at max gross weight. PreciseFlight speedbrakes are installedbut function intermittently (and are currently disabled). I've never felt the need for them
you can descend at cruise power and 2000 FPM without nearing Vne and it's easy to slow down so I've never bothered to diagnose the issuebut the equipment is there if you want to. BFG WX-950 Stormscope JPI EDM730 Engine Monitor
which exports logs to a standard USB drive Artex 406 MHz ELT Fully-articulating front seats. Split fold-down and removable rear seats make a large
flat cargo space. 4 Place intercom with line-in port Electric elevator and rudder trim Leather interior and all liners in good condition. Worn carpet below the pilot rudder pedals. Landing gear "donuts" in good condition
Description
Avionics / Equipment Primary instruments are dual Garmin G5s (solid-state AHRS), configured for reversionary mode, with a backup battery. Backup analog instruments are an altimeter, airspeed indicator, vertical speed indicator, electric turn coordinator, and two electric attitude indicators. There is no vacuum system. Garmin GFC 500 Autopilot with flight director, altitude/VS/IAS pre-select, glideslope coupling, GPSS roll steering, return to level (LVL), and Electronic Stability Protection (ESP). All autopilot servos were replaced with updated "mod 1" units in 2025. WAAS-capable Garmin 430W navigator, which can fly LPV approaches Garmin GTX 345 transponder; ADS-B in and out with Bluetooth KX 165 secondary NAV/COMM radio KMA 24 audio panel Dual main batteries, dual alternators, external GPU plug Monroy long-range tanks, 118 gallons usable All fuel tanks stripped and re-sealed with the Weep-No-More process in 2012 TKS system certified for flight into known icing conditions (FIKI), with dual pumps 115 cu ft integrated four-place oxygen system, with a two-place O2D2 pulse-demand unit included Redline SideWinder battery-operated tow bar. One person can move the plane easily, even at max gross weight. PreciseFlight speedbrakes are installed, but function intermittently (and are currently disabled). I've never felt the need for them - you can descend at cruise power and 2000 FPM without nearing Vne, and it's easy to slow down - so I've never bothered to diagnose the issue, but the equipment is there if you want to. BFG WX-950 Stormscope JPI EDM730 Engine Monitor, which exports logs to a standard USB drive Artex 406 MHz ELT Fully-articulating front seats. Split fold-down and removable rear seats make a large, flat cargo space. 4 Place intercom with line-in port Electric elevator and rudder trim Leather interior and all liners in good condition. Worn carpet below the pilot rudder pedals. Landing gear "donuts" in good condition
Engine
Lycoming TSIO-540-AF1B, 270 HP - 1800 TTSN McCauley 3-blade propeller - 1131 hrs SPOH (Dec 2008) It's well-equipped for both cold weather (Tanis engine pre-heat system) and humidity (a stand-alone refrigerant-based engine dehydrator). I have complete oil analysis records since I purchased the aircraft in 2020, during which time I've used CamGuard and/or Aeroshell W100+. I installed a modern JPI engine monitor in 2021, and have complete engine data since. It's borescoped at every oil change. I operate LOP in cruise at 14 GPH, which gives 175 KTAS at reasonable altitudes, and CHTs below 380ºF. You can of course burn more gas and go faster: it will do 182 KTAS at 18 GPH, or 196 KTAS at 20 GPH. Piston pin plugs began to wear in 2021 (a known issue for this vintage of Lycoming), and were replaced with new plugs in all 6 cylinders. Complete exhaust system overhaul in October 2024. No other issues in the 5 years that I've flown it. Will provide complete engine monitor data on the Savvy Aviation platform dating back to 2021.
Description and equipment details provided by the seller. AeroGurus does not verify seller-provided information.
Price Comparison 1 active offer
| Source | Price | Location | Listed | Days on Market | Status | Action |
|---|---|---|---|---|---|---|
|
Phil Schwan
trade-a-plane.com
|
$250,000
|
Hollywood, FL | May 05, 2026 | — | Active |
Estimate Monthly Payment
Mooney M20M Tls Bravo loan calculator
AeroGurus Data & Analysis
Independent data from FAA, NTSB, and market analysis
About This Mooney M20M Tls Bravo
This 1998 Mooney M20M Tls Bravo (N21538) is a 4-seat single engine piston with 1,815 hours on the airframe. There are currently 4 M20M Tls Bravo aircraft listed for sale with asking prices ranging from $105,000 to $250,000. This aircraft is priced above the market average at $250,000.
Operating costs: Fuel burn is 16 GPH (61 L/h), which at current Jet-A prices (~$5.50/gal) means approximately $88/hr in fuel alone. Total variable cost including maintenance reserves is approximately $180/hr. Annual fixed costs (hangar, insurance, crew, annual inspection) average $22,000. With 1,815 hours on the airframe, this aircraft has 185 hours remaining to engine TBO .
NTSB records show 0 incidents for this airframe — a clean safety record.
